PK328P5UW.26/4096 Hohner Rotary Encoder
| Body Diameter |
80mm |
|---|---|
| Output Circuit |
RS422 (TTL) |
| Resolution |
4096 PPR |
| Shaft Size |
32mm |
| Shaft Type |
Hollow Shaft |
| Technology |
Incremental Encoder |
PK328P5UW.26/4096 Hohner Incremental Hollow Shaft Rotary Encoder
The Hohner PK328P5UW.26/4096 Incremental Rotary Encoder is a high-precision industrial-grade encoder featuring a 32 mm hollow shaft, 80 mm body diameter, and an impressive 4096 pulses per revolution (PPR) resolution. Designed for demanding applications such as motor feedback, position tracking, and automated machinery, this encoder delivers reliable AB0 + AB0 differential push-pull output signals compatible with TTL logic, supporting a wide voltage range of 5–28V. Its robust mechanical design, M23 12-pin radial connector, and noise-resistant signal output make it ideal for use in harsh industrial environments where precision, durability, and secure connectivity are essential. The hollow shaft allows for direct shaft mounting without the need for coupling, reducing installation complexity and increasing system efficiency. Built for long-term reliability and high-speed operation, the Hohner PK328P5UW.26/4096 is widely used in textile machinery, elevators, CNC systems, packaging lines, and automated production equipment.
Now available with expert support and the best pricing from EncoderMarket.com.
For detailed specifications, fast delivery, and personalized technical assistance, contact us today at info@encodermarket.com.
DATASHEET (Hohner PK Serie Encoder Technical Specification.pdf)
Hohner PK328P5UW.26/4096 – High-Resolution Incremental Hollow Shaft Rotary Encoder for Industrial Applications
The Hohner PK328P5UW.26/4096 is a high-resolution incremental rotary encoder featuring a 32 mm hollow shaft, engineered for demanding industrial environments that require precision, durability, and reliable signal output. Designed and manufactured by Hohner, a trusted name in motion control, this encoder provides 4096 pulses per revolution (PPR) and is ideal for applications such as motor feedback, automation systems, and position tracking.
Technical Specifications
-
Model: PK328P5UW.26/4096
-
Encoder Type: Incremental Rotary Encoder
-
Shaft Type: Hollow Shaft
-
Shaft Size: 32 mm
-
Body Size: 80 mm
-
Resolution: 4096 PPR
-
Output Signals: AB0 + AB0 (differential output, push-pull), 5–28V
-
Compatible with TTL
-
Low Level Output: < 0.5V
-
High Level Output: > Vcc – 1.9V
-
-
Electrical Connection: M23 12-pin (9416 Radial) connector
-
Signal Type: Push-Pull (PP) output suitable for long cable runs and industrial noise immunity
Key Features
-
High Resolution: With 4096 pulses per revolution, this encoder supports fine measurement and control in both low and high-speed systems.
-
Robust Hollow Shaft Design: The 32 mm hollow shaft allows direct installation on motor or shaft ends without requiring coupling, reducing mechanical wear and simplifying integration.
-
Wide Voltage Range Output: Push-pull output supports a broad input voltage range (5 to 28V), ensuring compatibility with various PLCs and controllers.
-
Durable Industrial Housing: 80 mm body ensures strong mechanical stability and long-term durability in harsh operating conditions.
-
Secure Connection Interface: Equipped with a rugged M23 12-pin radial connector, offering a secure and reliable signal interface for industrial use.
Application Areas
-
Motor Feedback Systems
-
Elevators and Lifting Equipment
-
Packaging and Printing Machines
-
Textile and Woodworking Machinery
-
Positioning and Speed Control in Industrial Automation
Why Choose the Hohner PK328P5UW.26/4096 Encoder?
The Hohner PK328P5UW.26/4096 stands out with its high resolution, robust construction, and versatile output compatibility, making it a top choice for engineers and system integrators in various industries. Its 32 mm hollow shaft simplifies installation, and its differential output provides strong signal integrity over long cable distances in electrically noisy environments.
